GENSETS - 250kVA / 320kVA - Power Express Generators

GENSETS – 250kVA / 320kVA

Features:

Compat Design

Its Recovery Time, Easily The Best In Its Category, Guarantees A Seamless Switchover To The Back-Up Power. Moreover, Its Effective Governing System Controls The Voltage Fluctuations, Thus Ensuing Complete Safety Of Your Equipment.

Large Fuel Tank

Its got one of the most preferred engines fitted inside – the Mahindra Powerol engine. Compact and low on vibration, this engine has the smallest footprint as compared to other engines of identical ratings. Making the DG set apt even for roof-mountings.

Longer Engine Life

Each and every Powerol DG set complies with the most stringent noise and emission norms stipulated by the Central Pollution Control Board of India (CPCB).

Low Maintenance Cost

It’s got other advantages too. Like, it’s transported through the Mahindra Transport Solutions Group. It is installed and commissioned through a Mahindra authorized dealer. It even comes with an annual maintenance contract. It is most fuel efficient in its class It offers zero-leak engines Manual and AMF control panel options are also available.

Preferred by All

A Powerol DG set can be used in the Telecom, Defence and Railway sectors. It can also be installed at places like petrol pumps, hospitals, super markets, banks and construction sites.

Description

Silence is Golden: India’s most silent Genset brand

Mahindra Powerol’s ‘Spectro’ series of diesel gensets is one of the most silent gensets manufactured by the brand. It has sturdy wheels and a long handle which allows easy mobility of the genset.

Assurance

Power fluctuations can affect your business as well as day to day operations. Diesel gensets act as back up against power cuts providing you with uninterrupted power supply. Mahindra Powerol has a wide network of authorized dealers & skilled service engineers spread across India. Customers just need to dial our Toll-free number – 1-800-419-1999 & service will be available at the doorstep.

Over 400 sales and service touch points.
Easy Finance schemes available.
Fuel Efficient Engines.

Appliances that can run on 250kVA Gensets

2 Televisions

2 Air Conditioners

2 Wi-Fi Modems

6 Light Bulbs

2 Printers

2 Laptops

1 Coffee Maker

Segments used for:

Bungalows, Small Offices, Small Shops

Technical Specifications

PARAMETERS	DG MODELS
Genset Prime Rating (kVA) *	250kVA
Genset Prime Rating (KW)	200 KW
Phase / Voltage (V)	3 / 415
No of Phases	1/3
Power Factor	0.8 (lagging)
Current (A) (3Phase)	348
Frequency (Hz) & RPM	50/1500
Governing class	G2
Starting system	24 V DC Elec
Fuel tank capacity	425
Genset Dimension (LxWxH) (mm) Approx.	3990 x 1500 x 1770
Genset Weight (kg) approx.	3300
Engine Specification
Make / Series	Mahindra mPower
Engine Model	mPower63105G
Rated Power at 100% Load @ 1500 RPM (HP)	310
Aspiration	Turbocharged Aftercooled
No. of cylinders	6
Bore x Stroke (mm)	116.6 x 146.1
Displacement (Lit)	9.3
Fuel consumption @ 75% load (lit/hr) ^	41.2
Fuel consumption @ 100% load (lit/hr) ^	54.1
Lube oil specification	15W40 CI4+
Lube Oil Refil Quantity (Lit)	30
Lube oil consumption @ 100% load ($)	0.1% of Fuel Consumption
Lube oil change period (hrs.)	500
Radiator coolant capacity (liter)	31
Alternator
Make	CG/Stamford
Enclosure Type	IP23
Voltage regulation	±1%
Class of insulation	Class H
Maximum Unbalanced Load across Phases	25%

**Alternator Configuration available

Above specifications are subject to change without prior notice due to continuous product improvements.
All engines & alternators confirm to respective IS standards
All the genset specifications are as per ISO 8528 standard
* For Standby duty, contact Powerol authorized representative
All specifications are at standard NTP operating conditions
All specifications are at standard NTP operating conditions
All the above gensets conform to the latest CPCB norms of <75 dbA

Appliances that can run on 320kVA Gensets

4 Televisions

3 Air Conditioners

3 Wi-Fi Modems

12 Light Bulbs

3 Printers

4 Laptops

2 Coffee Maker

Segments used for:

Bungalows, Small Offices, Small Shops

Technical Specifications

PARAMETERS	DG MODELS
Genset Prime Rating (kVA) *	320 kVA
Genset Prime Rating (KW)	256 KW
Phase / Voltage (V)	3 / 415
No of Phases	1/3
Power Factor	0.8 (lagging)
Current (A) (3Phase)	445
Frequency (Hz) & RPM	50/1500
Governing class	G2
Starting system	24 V DC Elec
Fuel tank capacity	570
Genset Dimension (LxWxH) (mm) Approx.	4550 X 1600 X 1780
Genset Weight (kg) approx.	3550
Engine Specification
Make / Series	Mahindra mPower
Engine Model	mPower63905G
Rated Power at 100% Load @ 1500 RPM (HP)	390
Aspiration	Turbocharged Aftercooled
No. of cylinders	6
Bore x Stroke (mm)	116.6 x 146.1
Displacement (Lit)	9.3
Fuel consumption @ 75% load (lit/hr) ^	51.5
Fuel consumption @ 100% load (lit/hr) ^	67.4
Lube oil specification	15W40 CI4+
Lube Oil Refil Quantity (Lit)	30
Lube oil consumption @ 100% load ($)	0.1% of Fuel Consumption
Lube oil change period (hrs.)	500
Radiator coolant capacity (liter)	45
Alternator
Make	CG/Stamford
Enclosure Type	IP23
Voltage regulation	±1%
Class of insulation	Class H
Maximum Unbalanced Load across Phases	25%

**Alternator Configuration available
